High-quality products
are our core competitiveness
Real field cases verify the quality of the equipment and gain unanimous praise and repurchase from customers.
| Series | Standard Model | On board equipment | On board equipment | Processing Capability(t/h) | Transport Dimensions(mm) |
| FOUR COMBINATION MOBILE PIANT | MTF100Y-2 | GZD850×3000/2YK1545 | HD72/GYS300 | 50-100 | 15000×2650×4500 |
| MTF100Y-3 | GZDT0835/3HX1548 | HDX86/SC100F1 | 50-100 | 17500×2500×4000 | |
| MTF150Y-3 | GZDT0835/3HX1548 | HDX86/SC160F1 | 70-150 | 17500×2500×4000 | |
| MTF150R-3 | GZDT0835/3HX1548 | HDX86/C1110 | 60-150 | 17500×2500×4000 | |
| THREE COMBINATION MOBILE PIANT | MTF1213-Ⅲ | GZDT9538/3HX1865 | CI1213 | 80-200 | 18200×2800×4350 |
| MTF1316-Ⅲ | GZDT1145A/3HX2165 | CI1316 | 100-300 | 18200×3000×4200 | |
| MTF1410-Ⅲ | GZDT9538/3HX1865 | PCZ1410 | 80-200 | 18200×2800×4200 | |
| MTF1612-Ⅲ | GZDT1145A/3HX2165 | PCZ1612 | 100-300 | 18200×3000×4200 | |
| MOBILE COARSE CRUSHING PIANT | MTF96 | GZDT9538 | CJ96 | 70-200 | 13000×2950×4250 |
| MTF98 | GZDT9538 | HDX98 | 80-200 | 13000×2950×4250 | |
| MTF106 | GZDT1145A | CJ106 | 90-300 | 14000×3000×4400 | |
| MTF110 | GZDT1145A | HDX110 | 120-300 | 14000×3000×4400 | |
| MTF120 | GZDT1245 | CJ120 | 175-500 | 14000×3000×4300 | |
| MTF125 | GZDT1245 | HDX125 | 280-550 | 14500×3100×4300 | |
| MTF1213C | GZDT9538 | CI1213 | 80-200 | 13000×2950×4250 | |
| MTF1316C | GZDT1145A | CI1316 | 100-300 | 14000×3000×4400 | |
| MOBILE MEDIUMAND FINE CRUSHING PIANT | MTF300 | - | HPM300C1 | 100-200 | 15500×2900×4200 |
| MTF400 | - | HPM400C3 | 150-300 | 16500×3100×4300 | |
| MTF250 | - | SC250F1 | 90-200 | 16500×3100×4300 | |
| MTF1213 | - | CI1213 | 80-200 | 16000×2900×4300 | |
| MTF1316 | - | CI1316 | 100-300 | 16500×3100×4500 | |
| MTF0926 | - | HVI0926 | 85-200 | 16500×3100×4300 | |
| MTF1040 | - | HVI1040 | 120-300 | 16500×3100×4400 | |
| MOBILE SCREENING PIANT | MTF1865-3 | 一 | 3HX1865 | 65-200 | 14500×2900×4000 |
| MTF2165-3 | - | 3HX2165 | 85-300 | 15000×2900×4400 | |
| MOBILE PIANT FOR MEDIUMAND FINE CRUSHING AND SCREENING | MTF300S-3SⅡ | 3HX1865 | HPM300C1 | 100-200 | 15000×3000×4000 |
| MTF300S-3 | 3HX2165 | HPM300C1 | 100-200 | 15000×3000×4000 | |
| MTF400S-3 | 3HX2165 | HPM400C3 | 150-300 | 15000×3000×4000 | |
| MTFG400S-3SⅡ | 3HX1865 | GYS400C1 | 100-200 | 15000×3000×4000 | |
| MTFG400S-3 | 3HX2165 | GYS400C1 | 100-200 | 15000×3000×4000 | |
| MTF250S-3 | 3HX2165 | SC250F1 | 90-200 | 15000×3000×4200 | |
| MTF1213S-3 | 3HX1865 | CI1213 | 80-200 | 15000×3000×4200 | |
| MTF1316S-3 | 3HX2165 | CI1316 | 100-300 | 15000×3000×4200 | |
| MTF0926S-2 | 2HX1865 | HVI0926 | 85-200 | 18000×3000×4200 | |
| MTF1040S-2 | 2HX2165 | HVI1040 | 120-300 | 18000×3000×4200 |
Note: Processing capacity may vary with different materials and feeding sizes.
| Series | Standard Model | Processing Capability(t/h) |
| FOUR COMBINATION MOBILE PIANT | MTF100Y-2 | 50-100 |
| MTF100Y-3 | 50-100 | |
| MTF150Y-3 | 70-150 | |
| MTF150R-3 | 60-150 | |
| THREE COMBINATION MOBILE PIANT | MTF1213-Ⅲ | 80-200 |
| MTF1316-Ⅲ | 100-300 | |
| MTF1410-Ⅲ | 80-200 | |
| MTF1612-Ⅲ | 100-300 | |
| MOBILE COARSE CRUSHING PIANT | MTF96 | 70-200 |
| MTF98 | 80-200 | |
| MTF106 | 90-300 | |
| MTF110 | 120-300 | |
| MTF120 | 175-500 | |
| MTF125 | 280-550 | |
| MTF1213C | 80-200 | |
| MTF1316C | 100-300 | |
| MOBILE MEDIUMAND FINE CRUSHING PIANT | MTF300 | 100-200 |
| MTF400 | 150-300 | |
| MTF250 | 90-200 | |
| MTF1213 | 80-200 | |
| MTF1316 | 100-300 | |
| MTF0926 | 85-200 | |
| MTF1040 | 120-300 | |
| MOBILE SCREENING PIANT | MTF1865-3 | 65-200 |
| MTF2165-3 | 85-300 | |
| MOBILE PIANT FOR MEDIUMAND FINE CRUSHING AND SCREENING | MTF300S-3SⅡ | 100-200 |
| MTF300S-3 | 100-200 | |
| MTF400S-3 | 150-300 | |
| MTFG400S-3SⅡ | 100-200 | |
| MTFG400S-3 | 100-200 | |
| MTF250S-3 | 90-200 | |
| MTF1213S-3 | 80-200 | |
| MTF1316S-3 | 100-300 | |
| MTF0926S-2 | 85-200 | |
| MTF1040S-2 | 120-300 |
Note: Processing capacity may vary with different materials and feeding sizes.
